Befaco - InAmp
The unit is designed to amplify up to x20 the input signal, allowing to amplify most of the music machines out there (Domestic line levels) as well as some guitars (Humbucker-like pickups and so).
DIY-Kit-Type:
THT-Kit-1. This is a Do-It-Yourself kit, not an assembled module. The kit includes all parts to build the module. Only trough-hole parts to solder. Make sure to check the build guide before you buy. For build guide, more info, videos etc. please check the buttons below.
| Current draw +12 V [mA]: | 21 |
|---|---|
| Current draw -12 V [mA]: | 10 |
| DIY Level: | Easy |
| Depth [mm]: | 30 |
| Width [HP]: | 4 |
| Format: | 3U |
| Panel / Color: | Black Alu |
